Limitless 16×16 RGB Vertical Bending
LIMITLESS Premium NEON Flex RGBW - 24Volt CV
Feature:
LIMITLESS Premium NEON Flex V RGB+W 3000K light made of Flexible printed circuit technology (FPC), encapsulation polyurethane offering ultimate waterproof, UV resistance, available in 15 Watt, adaptable for outdoor applications. LED mono color, diffused light effect 150°, using LEDs high performance with CRI 90+. Cable length 1000mm.
Protection IP67
Operating ambient temperature from -25°C to 45°C.
LIMITLESS 16×16 Vertical Bending
Specification Product
| Wattage | 15Watt/meter “reel 5 meters” |
| CRI | ≥90+ |
| SDCM | SDCM≤3 single BIN |
| CCT | RGB+W 3000K |
| Light distribution | Diffused |
| Efficiency | up to 62.5 lm/W |
| IP | 67/68 |
| IK | 10 |
Technical Data
| Application | Surface – Recessed |
| Finish | Polyurethane Resin |
| Dimension | 16x16x5000 mm & Custom |
| Profile | Not Included |
| Fitting Life | L90 B10 (Ta ,25°C) – Reported TM-21 L70 Lifetime: >54000 hours |
PRODUCT SELECTION
1
Step 1
CCT - LUMEN(DELIVERED) - CRI - SDCM
| Watt/mt | CRI | SDCM | RGB + 3000K |
| 15 | 90 | ≤3 | 575 |
Download
ACCESSORIES
L-AL037 – Kit Aluminum Profile U 1000*19*18
L-AL041 – Kit Aluminum Profile U 2000*19*18
L-AL038 – Kit 10 nos Aluminum Profile U 30*19*18mm
L-AL045 – Kit Aluminum Profile U 1000*19*39
L-AL046 – Kit Aluminum Profile U 2000*19*39
L-AL043 – Kit Aluminum Profile Frame 1000*27*18
L-AL044 – Kit Aluminum Profile Frame 2000*27*18
L-AL047 – Kit Aluminum Profile Frame 1000*27*36
L-AL048 – Kit Aluminum Profile Frame 2000*27*37
D001
On/Off IP67 75Watt
D004
On/Off IP67 150Watt
DMX002
DMX 240Watt
